High Torque Precision Right Angle Gearbox combines a high precision planetary gearbox with a spiral bevel gearbox, often used for servo motors to achieve high precision and efficiency. Cubic shape, small sizes 65*65*65mm to large sizes 280*280*280mm Square box. A compact structure with integrated alloy aluminum body for maximum rigidity and corrosion resistance, easily assembled with multiple precision components. Rated torque capacities from 25Nm to 3200Nm. Available transmission gear ratios 1:1 and 2:1(1-stage). 3:1, 4:1, 5:1, 6:1, 8:1 and 10:1 (2-stage). 9:1, 12:1, 15:1, 16:1, 20:1, 25:1, 30:1, 32:1, 40:1, 50:1 (3-stage). The simplified structure design with high torque, high speed and low backlash applies to applications of precision servo. Easy mount, low noise, low vibration, maintenance-free under normal operating conditions, no need to replace the grease and long service life. Typical applications for these precision gear reducers include precision rotary axis drives, traveling gantries and columns, material handling axis drives, aerospace, CNC, AGV, machine tool and robotics and electronic line shafting.
