Spiral Bevel Gearbox Torque 40Nm Power 6kW

Spiral Bevel Gearbox Torque 40Nm Power 6kW are often used in hoisting equipment, paper folding machine, entertainment facility, multistory packing structure for transporting pallets. Available in 1:1, 1.5:1, 2:1, 3:1, 4:1 and 5:1 gear reduction ratios. 2-way, 3-way and 4-way configurations, custom 5-way gearboxes. Available in solid shaft and hollow output shaft configurations, and integrated motor adapter design. Allows both horizontal and vertical shafts. The gear transmission average efficiency up to 95%. Angular transmissions has an high/power size ratio and a very low noise working, even at high running speed. cubic case made of high grade spheroidal cast iron and milled on all the surfaces so to be fixed in every position by the threaded holes. All the gears are fully produced in our factory, assembled from our specialised technical with minimum backlash. That mean high quality standard with low angular clearance and the possibility to meet every customer request.

Product Catalog

Square Bevel Gearbox.pdf

Product Dimensions

Free 2d .dwg, .dxf drawing, 3d cad models.
