5 Ton Screw Jack

5 Ton Screw Jack with self-locking trapezoidal screw Tr40x7. Its advantages includes Positive, mechanical positioning, Uniform lifting speed, Multiple arrangements and Anti-backlash feature (optional). Gear ratios include 6:1, 12:1 and 24:1. Design Configurations: Standard Design (Translating Screw), Rotating Design (Traveling Nut) and Keyed Design. The machine screw jacks can be arranged in systems to provide synchronized travel when driven from a common source. Jacks are available with one of four standard end conditions or special ends to meet your requirements. All jack designs can be fitted with protective boots. We can customize machine screw jacks to meet your specifications.

Product Catalog

Standard Machine Screw Jack.pdf

Product Specifications

Product Dimensions

Free 2d .dwg, .dxf drawing, 3d cad models.
